2 F X 2.5 mm2 solid bared Copper Stranded 450V / 750V 70℃ PVC
Jacket Flat Cable
Product Description
Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor
Product character:
Flame rated :FT2
Tensile strength:≥10.3 MPa Elongation:≥100%
Aged condition:113±1℃×168h
Percent of original tensile strength: ≥70%
Percent of original elongation: ≥65%
UL758
-E258652-20060111-CertificateofCompliance-1....
| ITEM | 2F×2.50mm2(1/1.78B) |
| CONDUCTOR | Material | Bared copper solid |
| Size | 1/1.78mm |
| O.D.(Ref) | 1.78mm |
| INSULATION | Material | PVC |
| Min. average thickness | 0.80mm |
| Min. thickness at any point | 0.64mm |
| O.D.(Ref) | 3.40±0.20mm |
| DRAIN | Material | Bared copper solid |
| Construction | 1/1.78B |
| JACKET | Material | PVC |
| Min.average thickness | 1.00mm |
| Min.thickness at any point | 0.80mm |
| O.D. | (10.50±0.40)mm×(5.40±0.20)mm |
Insulation:PVC
Conductor : Bared copper solid
Construction
Insulation:green&brown
Jacket : per request
Jacket: PVC
Application
These cables are appropriate for flexible use with medium
mechanical stresses, and free movement without tensile stress or
forced movements in dry, moist and wet rooms but not open air.
Suitable to be used as measuring and control cables in tool
machines,
Standards
International:
RoHS,REACH Compliant,
Rated voltage:450V/750V
Rated Temperature: 70℃
Voltage withstand test:AC 2.0kV/1min
Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively oil resistant
Flexible
| PHYSICAL PROPERTIES |
| Tensile strength: | ≥10.3MPa |
| Elongation: | ≥100% |
| Aged condition: | 113±1℃×168h |
| Percent of original tensile strength: | ≥70% |
| Percent of original elongation: | ≥65% |
